Cultivation Stone Tiller
Recycling – Breaking – Mixing
The HEN cultivation tiller RBM-S is used to crush branches, brushwood, stones, roots and other useless material and to process the soil so that it can be used again.
Cultivation Stone Tiller
Recycling – Breaking – Mixing
The HEN cultivation tiller RBM-S is used to crush branches, brushwood, stones, roots and other useless material and to process the soil so that it can be used again.
About the HEN product: RBM-S
With the HEN RBM-S mounted stone tiller you can recycle-crush-mix. And all this with only one tiller.
Ideally suited for road and path construction as well as for soil improvement.
Technical data:
- Rotor outer diameter: 910 mm
- Milling rotor with round shank chisels Ø 35
- Made of highly resistant carbide steel
- Slow turning rotor
- Attachment base cat. III / IV
- Power class from 220 kW to 450 kW
- Working width: 1,800 mm to 2,300 mm
- Central gearbox with 1 3/4 Z20
- PTO connection 1,000 rpm
- Two-sided rotor drive via rotor speed 260 rpm
Features:
- Slow-turn milling rotor
- Two-sided rotor drive via patented gearwheel system
- Housing made of Domex special steel
- Wear plates made of Hardox 400 screwed together
- Working depth up to max. 300 mm with solid surface (up to 400 mm with loose surface)
- Asphalt roads up to 24 cm pavement thickness without previous tearing up of the asphaltLangsamdrehender Fräsrotor
Areas of application:
- Subgrade stabilization: Milling of lime-cement mixture
- Road construction and maintenance
- For milling and mixing the wearing course on gravel roads with all types of road construction materials
- For milling and mixing root residues, broken wood and rootstocks in wild meadows, clear cuts and construction sites
- For crushing stones in vineyards or arable land in order to avoid consequential damage during further processing with other machines
More Information:
Recultivation involves measures to restore a landscape or terrain. With the HEN forest cutter and stone cutter you will succeed in an optimal recultivation.
- Crushing of branches, brushwood, stones, roots and other useless material
- Soil cultivation for reuse
- Incorporation up to 40 cm into the subsoil
